Product Details:
|
Applicable Industries: | Manufacturing Plant, Food & Beverage Factory, Farms, Home Use, Retail, Other | Showroom Location: | None |
---|---|---|---|
Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
Marketing Type: | Ordinary Product | Warranty Of Core Components: | 1 Year |
Core Components: | Brandy Filter Housing, Polypropylene Yarn | Condition: | New |
Voltage: | 220V | Power: | 0.5 |
Dimension(L*W*H): | Standard | Weight: | 0.16 Kg |
Warranty: | 1 Year | Product Name: | PP Wound Cartridge Water Filter |
Application: | Water Purification | Use: | Pre Filtration |
Material: | PP Materials | After-sales Service Provided: | Online Service |
Length: | 10" 20" 30" 40 Inch | Authentication: | ISO9001 |
Brand | HuiSiDun | ||||||
Product Name | Wire wound water filter | ||||||
Filter media | PP cotton or glass fiber | ||||||
Core | PP or stainless steel | ||||||
Length | 10" 20" 30" 40" 50" 60" | ||||||
Outside diameter: | 60 ~ 115 mm | ||||||
Inner diameter | 28mm 30mm | ||||||
Micron Rating | 1 5 10 20 30 50 75 100 µm | ||||||
Maximum operating pressure: | 0.4 kft/cm² | ||||||
Maximum Differential Pressure | 2 kgf/cm² | ||||||
Max. Operating Temperature: | PP ≤ 80°C;Cotton ≤ 120°C;Glass fiber ≤ 180°C | ||||||
Seal Material | Silicone,EDPM,Buna,Viton, Teflon |
