Product Details:
|
| Condition: | New | Applicable Industries: | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Food & Beverage Shops, Other, Advertising Comp |
|---|---|---|---|
| Showroom Location: | United States, Brazil, Indonesia | Video Outgoing-inspection: | Provided |
| Machinery Test Report: | Provided | Marketing Type: | Ordinary Product |
| Warranty Of Core Components: | 1 Year | Core Components: | Gearbox, Gear, Engine, Motor |
| Material: | Plywood Case, Wooden Case | Size: | Different As Each Model |
| Warranty: | 1 Year | Productivity: | 500L/Hour |
| Weight (KG): | 6 Kg | Product Name: | Water Treatment System Processing Reverse Osmosis Plant |
| Type: | Pure Water Treatment System | Function: | Reverse Osmosis Water Purification |
| Color: | Yellow | Application: | Large Water Filtration |
| MOQ: | 100 | Usage: | Water Treament |
| Keywords: | RO Water Filtration | Filter: | Soften Water Filter |
|
Model
|
A, mm (inch)
|
B, mm (inch)
|
C, mm (inch)
|
D, mm (inch)
|
|||
|
BW/LP-8040
|
1016 (40)
|
201 (7.9)
|
29 (1.125)
|
//
|
|||
|
BW/LP-4040
|
1016 (40)
|
96 (3.8)
|
19 (0.75)
|
27 (1.05)
|
|||
|
Specifications
|
8040
|
4040
|
8040
|
4040
|
|||
|
Material
|
Aromatic polyamide
|
Aromatic polyamide
|
Aromatic polyamide
|
Aromatic polyamide
|
|||
|
Structure
|
Spiral-wound
|
|
|
|
|||
|
Effective Membrane Area(m²)
|
37
|
7.6
|
37
|
7.6
|
|||
|
Thickness of the inlet grid(mil)
|
34
|
|
|
|
|||
|
Standard Test Solution
|
2000mg/L NaCl
|
|
1500mg/L NaCl
|
|
|||
|
Operating Pressure
|
1.55Mpa
|
1.55Mpa
|
1.05Mpa
|
1.55Mpa
|
|||
|
Test Temperature
|
25℃
|
|
|
|
|||
|
Recovery(%)
|
0.15
|
|
|
|
|||
|
pH
|
6.5~7
|
|
|
|
|||
|
Permeate Flow Rate(m3/d)
|
38/10000
|
7.6/2000
|
40/10500
|
8/2100
|
|||
|
Rejection(%)
|
99.5
|
|
99
|
|
|||
|
Max. Operating pressure
|
4.1Mpa (600Psi)
|
|
|
|
|||
|
Max. feed flow (GPM)
|
75
|
16
|
75
|
16
|
|||
|
Feed Temperature
|
5~45℃
|
|
|
|
|||
|
Feed pH
|
3~11
|
|
|
|
|||
|
Cleaning pH
|
2~12
|
|
|
|
|||
|
Max. feed turbidity
|
1
|
|
|
|
|||
|
Max. feed SDI15
|
5
|
|
|
|
|||
|
Residual Chlorine
|
< 0.1 mg/L
|
|
|
|
|||
|
Max. Pressure Drop each Element
|
15 psi
|
|
|
|
|||
